The Rising Role of Silicon in Energy Storage

The world of electronics is witnessing another shift in #energystorage #technology, as #silicon— the cornerstone of most electronic materials and computer chips—makes headway into the realm of #batteries. #Lithiumionbatteries, which have been a mainstay of energy storage for three decades, have witnessed significant progress, primarily on the #cathode side. However, the #anodes haven’t witnessed a similar evolution. Now, silicon, with its ability to store 10-times as many lithium ions by weight compared to graphite, is stepping into the spotlight as a promising material for anodes.

Getting Past Technical Obstacles on Silicon’s Road

Silicon’s path to prominence in #batterytechnology has been littered with technical roadblocks, such as volume expansion of the anode when laden with lithium ions, leading to material fracture. But after 15 years of incremental progress and unfulfilled expectations, silicon is finally coming into its own. And potentially unleashes a new era of battery technology.

Companies and silicon anode startups have begun partnering to create electric vehicles that offer greater range and affordability, set to hit the roads by the mid-20s. General Motors and OneD Battery Sciences, for instance, are integrating OneD Battery Sciences’s silicon nanotechnology into GM’s Ultium battery cells. Other companies like Group14 Technologies, Sila Nanotechnologies Inc., and Amprius Technologies have received substantial investment to commercialize their anode materials, with plans to establish large-scale manufacturing plants in the coming years.

Benefits of silicon anodes

The Promise: Greater Range and Fast Charging for EVs

Silicon’s entry into the battery sphere promises EVs with increased range, faster charging times, and more cost-effectiveness compared to current #EVbatteries that feature graphite anodes. Silicon’s high #LithiumIon absorption and swift transportation of these ions across the battery’s membrane, coupled with its abundance, ensures its potential for cheaper and more reliable supply.

Below is a summary of various advantages of silicon abode batteries over standard graphite anode batteries:

  1. Silicon anodes absorb more lithium than graphite anodes, resulting in significant improvements in battery performance.
  2. Silicon has a comparatively high theoretical-specific capacity, which means it can pack more energy into the same amount of space as graphite and other metal alloys, resulting in improved battery performance.
  3. Silicon-based batteries have a greater energy density than graphite-based batteries, which means they can store more energy in the same amount of space.
  4. Silicon anodes can enhance EV battery density and range without increasing costs.
  5. Silicon anodes can enhance battery capacity by up to 30%, resulting in greater range and faster charging times.
  6. Silicon anodes can cut the cost of EV batteries by up to 30%, making them more cost-effective than graphite anodes.

Innovations in Silicon Anode Design to Manage Expansion and Contraction in Silicon Anodes

The addition of silicon in batteries, however, is not without its challenges. The initial exploration of silicon for lithium battery anodes revealed issues with the anode’s disintegration due to drastic expansion and contraction during charging and discharging. To overcome these obstacles, several startups are focusing on nano-engineered silicon.

One such company, Amprius Technologies, has reported a silicon anode battery with an energy density of 500 watt-hours per kilogram—twice that of today’s lithium-ion based EV batteries. On the other hand, companies like OneD Battery Sciences are working on creating affordable EVs, leveraging silicon nanowires infused into graphite particles to create batteries with impressive energy densities and rapid charging times.

Sila Nanotechnologies Inc. and Group14 Technologies are focusing on silicon materials that mimic the appearance and behavior of the graphite powder used in current anodes. This approach allows for seamless integration at existing battery facilities. Sila’s design involves a composite that counteracts both major issues associated with silicon—the swelling and reactions with the electrolyte. Group14, leveraging its expertise in manufacturing porous carbon materials, creates porous carbon particles and then uses chemical vapor deposition to introduce silicon into the pores.

There are other paths to incorporating silicon into anodes. Enevate Corporation, for example, has developed a process to deposit porous silicon films directly on copper foil, while NanoGraf Corporation is making pre-swelled silicon oxide material to increase the amount of silicon in graphite anodes.

Silicon vs. Upcoming Battery Technologies

Despite the exciting progress in silicon anodes, competition from other emerging battery chemistries like lithium-metal, lithium-air, and lithium-sulfur cannot be overlooked. These technologies, however, are still in the developmental phase and carry certain risks. Therefore, for the foreseeable future, it seems that silicon is poised to take center stage in the battery industry. Well, potentially together with sodium-ion batteries.
